MAIS BUILT-IN SYSTEM (G.R)

MAIS built-in dripline (G.R) system is the latest addition to our irrigation products. It is supplied in 16 mm and 20 mm outside diameter. with 2 L/H.4 L/H and 8 L/H discharge rate for each size.



MAIS BUILT-IN DRIPLINE SYSTEM ADVANTAGES



-          Even water distribution over all irrigation rows

-          Easy cleaning of pipeline by flushing with high air or water pressure.

-          Made from linear low density polyethylene to withstand the harshest of field conditions, sun radiation, and all permitted chemicals and fertilizers common         agricultural use.

-          Drippers spacing can be adjusted according to the customer order

-          Less branching / submains required due to lower water friction losses.





System Diameters and Discharge Rates



Code	Nominal O. D . of  pipes ( mm )	W.T. (mm)	Discharge L/H
GR 16 --2	16	1.0	2 L / H
4	16	1.0	4 L / H
8	16	1.0	8 L / H
GR20 --2	20	1.0	2 L / H
4	20	1.0	4 L / H
8	20	1.0	8 L / H

--:Dripper spacing (cm)
